Asus PRIME Z790M-PLUS D4 90MB1D20-M0EAY0

PRIME Z790M-PLUS D4 ASUS Prime Z790M-PLUS D4, an Intel Z790 LGA 1700 mATX motherboard with PCIe 5.0, three M.2 slots, 10+1 DrMOS, DDR4, Intel 1 Gb LAN, HDMI, DP, USB 3.2 Gen...
5 397 Kč
Doprava 49 Kč,Skladem
Garantovaný nákup z ExaSoft.cz

Top nabídka

Seřadit:

Nejlevnější nabídky (9)

Skladem • 1 varianta59 Kč97 % • 11 400 recenzíDalší informace
Skladem • 1 variantaZdarma91 % • 1 639 recenzíDalší informace
Do 3 dnů • 1 variantaZdarma98 % • 53 156 recenzíShop roku '23 - FinalistaDalší informace
Do týdne • 1 varianta49 Kč96 % • 2 790 recenzíDalší informace
Skladem • 1 varianta79 Kč179 neověřených recenzíDalší informace
Skladem • 1 varianta49 Kč96 % • 39 419 recenzíDalší informace
Do obchodu
Do 3 dnů • 1 varianta79 Kč95 % • 6 182 recenzíDalší informace
Skladem • 1 varianta49 Kč95 % • 6 209 recenzíDalší informace
Do obchodu
Skladem • 1 variantaProdloužená zárukaZdarma90 % • 1 781 recenzíDalší informace
Do obchodu

Popis produktu

PRIME Z790M-PLUS D4 ASUS Prime Z790M-PLUS D4, an Intel Z790 LGA 1700 mATX motherboard with PCIe 5.0, three M.2 slots, 10+1 DrMOS, DDR4, Intel 1 Gb LAN, HDMI, DP, USB 3.2 Gen...

Parametry produktu

Výrobce
Patice
Socket 1700
Integrované grafické jádro
ne
Integrovaná zvuková karta
7.1
Pro procesory
Intel
Chipset
Intel Z790

Parametry produktu

Výrobce
Patice
Socket 1700
Integrované grafické jádro
ne
Integrovaná zvuková karta
7.1
Pro procesory
Intel
Chipset
Intel Z790

Popis produktu

PRIME Z790M-PLUS D4

ASUS Prime Z790M-PLUS D4, an Intel Z790 LGA 1700 mATX motherboard with PCIe 5.0, three M.2 slots, 10+1 DrMOS, DDR4, Intel 1 Gb LAN, HDMI, DP, USB 3.2 Gen 2x2 Type-C, front USB 3.2 Gen 1 Type-C, Thunderbolt™ (USB4) support, Arua Sync

  • Intel LGA 1700 socket: Ready for 12th and 13th Gen Intel processors
  • Enhanced power solution: 10+1 DrMOS, 6-layer PCB, ProCool connectors, alloy chokes and durable capacitors for stable power delivery
  • Next-gen connectivity: PCIe 5.0, Intel 1 Gb Ethernet, USB 3.2 Gen2x2 Type-C, front panel USB 3.2 Gen 1 Type-C, Thunderbolt™ (USB4) header support
  • ASUS OptiMem II: Careful routing of traces and vias, plus ground layer optimizations to preserve signal integrity for improved memory overclocking
  • Comprehensive cooling: Large VRM heatsinks, PCH heatsink, hybrid fan headers and Fan Xpert 4 with AI Cooling II

CPU

Intel Socket LGA1700 for 13th Gen Intel Core™ Processors & 12th Gen Intel Core™, Pentium Gold and Celeron Processors*

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0**

  • Refer to www.asus.com for CPU support list.
  • * Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset

Intel Z790 Chipset

Memory 4 x DIMM, Max. 128GB, DDR4 5333(OC)/5133(OC)/5066(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*

Dual Channel Memory Architecture

Supports Intel Extreme Memory Profile (XMP)

OptiMem II * Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.

Graphics 1 x DisplayPort** 1 x HDMI port***

  • Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
  • *Supports max. 4K@60Hz as specified in DisplayPort 1.4.
  • **Supports 4K@60Hz as specified in HDMI 2.1.

Expansion Slots

Intel 13th & 12th Gen Processors* 1 x PCIe 5.0 x16 slot

Intel Z790 Chipset 1 x PCIe 4.0 x16 slot (supports x4 mode) 2 x PCIe 4.0 x1 slots * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/). - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.

Storage

Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*

Intel 13th & 12th Gen Processors

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

Intel Z790 Chipset

M.2_2 slot (Key M), type 2260/2280 (supports PCIe 4.0 x4 mode)

M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) 4 x SATA 6Gb/s ports * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.

Ethernet 1 x Intel 1Gb Ethernet

ASUS LANGuard

Wireless & Bluetooth

M.2 slot only (Key E, CNVi & PCIe)* *Wi-Fi module is sold separately.

USB

Rear USB (Total 8 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 1 x USB 3.2 Gen 2 port (1 x Type-A) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A)

Front USB (Total 7 ports) 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports* * USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC*

  • Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • Supports up to 24-Bit/192 kHz playback

Audio Features

  • Audio Shielding
  • Premium audio capacitors
  • Dedicated audio PCB layers

* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 1 x USB 3.2 Gen 2 port (1 x Type-A) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Intel 1Gb Ethernet port 3 x Audio jacks

Internal I/O Connectors

Fan and cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers

Power related 1 x 24-pin Main Power connector 1 x 8-pin + 12V Power connector 1 x 4-pin + 12V Power connector

Storage related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports

USB 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports

Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x M.2 slot (Key E) 1 x S/PDIF Out header 1 x SPI TPM header (14-1pin) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt™ (USB4) header

Special Features

ASUS 5X PROTECTION III

  • DIGI+ VRM (- Digital power design with DrMOS)
  • LANGuard
  • Overvoltage Protection
  • SafeSlot Core+
  • Stainless-Steel Back I/O

ASUS Q-Design

  • Q-DIMM
  • Q-LED Core
  • Q-Slot

ASUS Thermal Solution - VRM heatsink design

  • ASUS EZ DIY
    • ProCool

Aura Sync

  • Aura RGB header
  • Addressable Gen 2 headers

Software Features

ASUS Exclusive Software

Armoury Crate

  • Aura Sync
  • Fan Xpert 4 (with AI Cooling II)
  • Power Saving

AI Suite 3

  • TurboV EVO
  • DIGI+ VRM
  • PC Cleaner

ASUS CPU-Z

Norton 360 Deluxe (60 Days Free Trial)

WinRAR

UEFI BIOS

  • ASUS EZ DIY
    • ASUS CrashFree BIOS 3
    • ASUS EZ Flash 3
    • ASUS UEFI BIOS EZ Mode

BIOS 192 (128+64) Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables 2 x SATA 6Gb/s cables

Miscellaneous 1 x I/O Shield 2 x Screw packages for M.2 SSD

Documentation 1 x User guide

Operating System

Windows 11, Windows 10 64-bit

Form Factor mATX Form Factor 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)

Chybí či je nepravdivý některý důležitý parametr? Uvedené informace jsou pouze orientační, před zakoupením ve vybraném obchodě doporučujeme ověřit, že prodávaný model má klíčové vlastnosti dle vašich požadavků. I když se snažíme o maximální přesnost informací, bohužel nemůžeme zaručit jeho 100% správnost. Ceny produktů jsou uváděny včetně DPH.
